Optimize Your Charging System

High output alternators are an important part of your system's battery care, but they are definitely not the only part.

Without proper voltage regulation, battery charging can be a slow process, or even worse, an ideal recipe for early battery failure.

Balmar's patented Max Charge and ARS-5 Voltage Regulators provide a dynamic method for monitoring battery condition and apply the correct level of alternator control (voltage and current) to ensure that your batteries are charged quickly and safely.

Max Charge MC-614 Voltage Regulator

Balmar MC-614 Voltage RegulatorOur Most Popular Regulator
  • 7 Selectable Programs for Marine Batteries
  • 15 Amp Maximum Field Current Advanced Programming Modes
  • Alternator & Battery Temperature Sensing & Control
  • Exclusive Belt Load Manager Function
  • Bright LED Display and Easy Programming Mode
  • Can be Used in Twin-Engine Applications with Centerfielder II (see below)
Balmar MC-614
Installation & Operation Manual




Max Charge MC-624 Voltage Regulator

Balmar MC-614 Voltage Regulator
  • Designed for 24 Volt Applications
  • 10 Amp Maximum Field Current
  • Can be Used in Twin-Engine Applications
  • All the Same Functions as the MC-614
Balmar MC-624
Installation & Operation Manual




Max Charge MC-612-Dual Voltage Regulator

Balmar MC-614 Voltage Regulator
  • Designed to Control 2 Alternators on a Single Engine
  • Dual Alternator & Battery Temperature Sensing
  • Twin 54” Wiring Harnesses Provided
  • All the Same Programming Functions as the MC-614
Balmar MC-612 Dual
Installation & Operation Manual




ARS-5 Voltage Regulator

Balmar MC-614 Voltage Regulator
  • 5 Selectable Programs for Marine Batteries
  • 9 Amp Maximum Field Current
  • Appropriate for 6-Series Alternators (150A and below)
  • Single Engine, Single Alternator Applications Only
  • All the Same Programming Functions as the MC-614
Balmar ARS-5
Installation & Operation Manual




Digital Duo Charge: DDC-12/24

Digital Duo Charge: DDC-12/24

Multi Bank Charging

  • The DDC is a Solid-State Battery Combiner
  • Control Voltage and Current between House and Start Batteries
  • Eliminates the Need for an Isolator, Relay or Manually Operated Battery Switch
  • Used in Concert with Max Charge or ARS-5 Regulators
  • Can also be Employed without a Balmar Regulator
  • Works in Both 12V and 24V Applications
  • House and Start Batteries can be different technologies
  • Start Battery Temperature Sensing Available with the MC-TS-B Sensor Cable
Balmar Digital Duo Charge
Installation & Operation Manual




Centerfielder II: CFII-12/2

Centerfielder II: CFII-12/2

Balanced Twin Engine Charging

  • Balances Charging in Twin Engine Applications
  • Eliminates Alternator Chatter by Unifying Field Current
  • For Use with Max Charge Regulators Only
  • Works in Both 12V and 24V Applications
  • Includes Upgraded Regulator Power Wires and Fusing
  • Isolates Alternators and Regulators when only One Engine is Running
  • Can be Used with the Digital Duo Charge to charge a Second Battery
Balmar Centerfielder II
Installation & Operation Manual



Selecting the appropriate Balmar Multi-Stage Regulator for your application can be a confusing process. The following chart matches the appropriate Balmar Regulator for each application and Balmar Alternator Series. Click on the Part Number to view a Product Data Sheet.

Preset, Multi-Stage
Battery Programs
Balmar Regulators Digital Duo Charge Dual Engine Centerfielder
12 Volt 24 Volt
ARS-5 MC-614 MC-612-DUAL MC-624 DDC-12/24 CFII-12/24
Universal Factory Program
Deep Cycle Flooded
Gel Cell
Absorbed Glass Mat (AGM)
Spiral Wound Flooded (Optima)
Yes Yes Yes Yes Yes Yes
Standard Flooded
Voltage Sensitive Halogen Systems
Yes Yes Yes Yes Yes
Balmar Alternator Models
6-Series Alternators
(70A-120A)
Yes Yes Yes Yes Yes Yes
AT-Series Alternator
(165A-200A)
Yes Yes Yes Yes
9-Series Large Case Alternators
(140A-310A)
Yes Yes Yes Yes Yes
Multiple Alternator/Engine Configurations
Dual Engine, One Alternator Each Yes
2 Required
Yes
2 Required
Yes Yes
Single Engine, Two Alternators Yes Yes
2 Required
Yes Yes


Single Stage Voltage Regulators



BRS-2T: Single-Stage Adjustable Voltage Regulator

BRS-2T: Single-Stage Adjustable Voltage Regulator




ERS-KIT Single Stage Voltage Regulator

BRS-2T: Single-Stage Adjustable Voltage Regulator

  • Ideal as an Inexpensive Backup Regulator
  • Kit includes Connectors To Connect to a Balmar 12V Regulator Harness
